Biosafety Cabinet Calss Il A1

Features

• Aerodynamic airflow grills maintain safety and prevent blockage.
• Air drawn through pre-filter passes through highly effective HEPA filters having efficiency ratings as high as 99.99% with cold DOP and 99.99% with hot DOP, retaining all airborne particles of size 0.1 micron and larger.
• The highly efficient HEPA/ULPA filter maintains optimum cleanliness and purity.
• Being equipped with a pre-filter, it extends the life of the HEPA/ULPA filter.
• 30% air exhaust.
• 70% air recirculation.
• HEPA filtered exhaust air in Type A1 cabinet may be recirculated into the room or exhausted outdoors through a canopy exhaust connection.
• HEPA filtered downflow air is a portion of mixed downflow and inflow air from a common plenum.
• U.V. and fluorescent interlock available.
• Ergonomic 10° sloped front window provides comfortable head and elbow rest positions, reducing fatigue.
• Sash is counterbalanced for smooth and lightweight operation with a standard opening of 200 mm ±10 mm for easier access and enhanced user safety.

Class-II Type A1 Biosafety Cabinet Protection

• Personnel protection from harmful agents used inside the biosafety cabinet.
• Product protection to avoid contamination of work, experiments, or processes from outside contaminants.
• Environmental protection from contamination of work, experiments, or processes.

Class-II Type A1 Biosafety Cabinet Key Features

• Front access opening with carefully maintained inward airflow.
• HEPA filtered, vertical, unidirectional airflow within the work area.
• HEPA filtered exhaust air to the room or to a facility exhaust system.

Class-II Type A1 Biosafety Cabinet Applications

• Type A1 cabinets are typically used for Biosafety Levels 1 through 3.
• Suitable for work with chemicals, provided vapors are not hazardous and do not interfere with the work when recirculated.
• Can be used with small amounts of chemicals when the cabinet is exhausted outdoors (optional configuration).

• Upper & Front Cover:
  Removable upper and front cover simplifies filter, blower, and front control panel replacement and makes maintenance easier.
• Material of Construction:
  • Internal working table is made of Stainless Steel (SS-304).
  • External cabinet is fabricated from SS-304 Steel or MS duly powder coated.
• Front Window / Sash:
  Front sash consists of thick plexiglass or optional toughened transparent glass for a clear interior view. It provides optimum resistance and protection against harmful UV rays, protecting users from ultraviolet radiation exposure.
• Drain Trough with Valve:
  The trough at the base is easy to clean and allows safe drainage of any liquid spillage.
• Decontamination by UV Lamp:
  UV lamp produces UV rays of 253.7 nm. The UV lamp and fluorescent lamp are interlocked, and the motor blower automatically turns off/on when the front sash is closed/opened. An optional timer controls the decontamination cycle, maximizes UV lamp life, and automatically switches the fluorescent lamp on after the cycle is completed.
• Splash Proof Electric Supply Socket:
  Splash-proof sockets are provided for convenient use of small electrical devices inside the cabinet.
• Front Airflow Intake Grid:
  Aerodynamically designed front airflow intake grid eliminates potential turbulence and contamination.
• Floor Stand and Castor Wheels:
  Heavy-duty tubular powder-coated floor stand fitted with durable castor wheels for smooth movement and a total brake system on the front wheels.
