ZEXTER B.O.D. INCUBATOR – MODEL NO. GGT-403
G. G. Technologies / TEXTER LAB SOLUTION
Manufacturer of Hospital, Institute, Industries, Agriculture, Pharmaceutical lab Testing Equipment’s
CONSTRUCTION DETAILS
- Cabinet Structure: BOD Incubators are double walled convection heated units designed for maximum thermal efficiency.
- Outer Body: Constructed out of thick PCRC sheet, duly pre-treated with primers and rust proofing, and finished with long-lasting stove enamel or elegantly powder coated.
- Inner Chamber: Made of heavy gauge stainless steel sheet of SS-304 grade.
- Insulation: The gap between the walls is filled with high grade mineral glass wool to ensure maximum thermal efficiency.
- Door System: Provided with two doors. The inner door is made of thick flexi glass/float glass with a magnetic door closer to view specimens without disturbing the chamber temperature. The outer door is made of mild steel sheet lined with stainless steel from inside and features a lock and key arrangement.
- Mobility & Placement: The unit is mounted on a sturdy steel frame and provided with caster wheels for easy movement inside the laboratory.
- Shelves & Air Circulation: Provided with three stainless steel shelves. The triple walled back of the incubator is equipped with two air circulation fans for uniform temperature maintenance throughout the chamber.
HEATING, COOLING & ILLUMINATION SYSTEMS
- Heating System: Indirect heating system comprising air heaters made of high grade Kanthal A-1 wires of suitable wattage. Warm air is evenly distributed via efficient motor fans to ensure excellent temperature sensitivity.
- Cooling System: Energy-efficient cooling unit installed to enable biochemical oxygen demand studies at lower room temperatures. Uses ISI marked, high-end CFC-free compressors of Kirloskar/Tecumseh make.
- Temperature Range: Standard temperature range spans from 5°C to 60°C (customers ki specialized requirement ke mutabik modify bhi kiya ja sakta hai).
- Illumination: Equipped with a door-operated illumination system comprising fluorescent lights.
- Control Panel: Front panel comprises on/off switches for heating and cooling, mains indicator lamps, temperature controllers, and voltmeters.
TECHNICAL PARAMETERS
| Parameter | Unit / Type | Specification Details |
|---|---|---|
| Temperature Sensitivity | ±°C | 0.5 or better |
| Spatial Deviation In Temperature | ±°C | 0.5 or better |
| Readability | °C | 0.51 |
| Temperature Range | °C | 5°C to 60°C (Standard) |
| Temperature Sensor | — | PT-100 |
| Temperature Controller | — | Solid State display Controller / PID (Optional) |
| Display | — | LED |
| Adjustable Alarm Limits | — | Optional (With PID controller only) |
| Safety Thermostats | — | Yes |
| Timer (999 mins) | — | Optional |
| Program (Real Time) | — | Optional |
| Data Acquisition Program | — | Optional |
| Serial Port (Printer) | RS 232C | Optional |
| Inspection Window in Door | — | Optional |
| Standard Shelves | — | 2 |
| Maximum Permitted Load Per Shelf | kg | 20/25 kg |
| Nominal Power | W | 1050 W |
| Nominal Voltage | V | 220/230 V |
| Phase / Frequency | Hz | 50 Hz, Single Phase |
