ORBITAL INCUBATOR SHAKER
Model No – GGT-1201H
G.G. TECHNOLOGIES
ZEXTER
MANUFACTURERS OF HOSPITAL, INSTITUTE, INDUSTRIES AGRICULTURE, PHARMACEUTICAL, LAB TESTING EQUIPMENTS
SALIENT FEATURES:
- Versatile usage
- Ergonomic Design
- Energy Efficient
- Long life
- Low Maintenance
CONSTRUCTION:
Our incubator shakers are double walled convection heated units. Outer body of our incubator shakers are constructed out of thick PCRC sheet duly elegantly powder coated. The inner chamber is made of heavy gauge stainless steel sheet of SS-304 grade. The gap between the walls is filled high grade mineral glass wool, which ensures maximum thermal efficiency in our incubator shakers.
The unit is provided with one doors, the inner door is made of M.S with glass window, to view the specimens without disturbing the temperature of the chamber. The outer door is made of mild steel sheet lined with stainless steel from inside. The unit is mounted on a sturdy steel frame. The walled back of our incubator shakers are provided with air circulation fans for uniform maintenance of the temperature throughout the chamber.
SHAKING SYSTEM:
The efficient and diligent shaking system of our incubator shaker has a orbital shaking movement which is powered by a reliable heavy duty DC motor.
SHAKING SPEED:
The variable shaking speed incubator shaker is between 25 RPM to 250 RPM.
SPEED CONTROL:
The orbital shaking in our orbital shakers is controlled by a DC drive which in turn is controlled through speed controller cum RPM indicator with great accuracy.
HEATING:
Indirect heating system is provided in our incubator shakers, comprising of air heaters made of high grade Kanthal A-1 wires of suitable wattage. The warm air is evenly distributed throughout the chamber through efficient motor fans ensuring very good temperature sensitivity.
ILLUMINATION:
Our units are provided with illumination system comprising of fluorescent lights.
FRONT PANEL:
Front panel of our units comprises of on/off switches heating, and mains indicator lamps, temperature controllers and voltmeters.
TEMPERATURE CONTROL:
Temperature control through Micro Processor Based Digital Temperature controlled cum Indicator Front panel of our units comprises of on/off switches heating, and mains indicator lamps, temperature controllers and voltmeters
CAPACITY & DISPLAY:
- FLASK CAPACITY: 100/250/500ml x 9 Erlenmeyer flasks
- Display: digital display for RPM and temperature
TECHNICAL PARAMETERS TABLE:
| Temperature Parameters: | ||
|---|---|---|
| Temperature Uniformity | ±°C | ±0.5°C |
| Temperature accuracy | ±°C | ±0.1°C |
| Temperature range | °C | Amb. 5-70°C |
| Temperature Sensor | PT-100 | |
| Temperature Controller | Micro Processor Based Temperature Controller | |
| Display | LED | |
| RPM | 25 to 250 | |
| Accommodating | 50ml, 100ml, 250ml, 500ml, 1000ml | |
| Automatic temperature setting | Yes (With PID Controllers only) | |
| Adjustable limits | Yes (With PID Controllers only) | |
| Power Consumption: | ||
| Nominal Power | W | 500 |
| Nominal Voltage | V | 220-230 Volts, |
| Frequency | Hz | 50 Hz Single Phase |
