Cooling Huminity Illumination Incubator GGT – 1111

ZEXTER COOLING HUMIDITY ILLUMINATION INCUBATOR – MODEL NO. GGT-1111

G.G. TECHNOLOGIES
Manufacturers of Hospital, Institute, Industries, Agriculture, Pharmaceutical, Lab Testing Equipments

APPLICATIONS

1. Used for normal germination applications and for various other tests involving micro-organisms, plants, tissues, electronic components etc.
2. Used for plant growth, biological studies, forestry research works, propagation of seeds, and incubation that requires a controlled environment (hot/cold cycles and light/dark operations).

CONSTRUCTION DETAILS

1. Cabinet Structure: Ultra-high-tech Triple walled Microprocessor controlled, solid-state incubator.
2. Outer Chamber: Made of Mild Steel duly pre-treated & finished with powder coated paint for a lasting finish.
3. Inner Chamber: Made of STAINLESS STEEL SHEET (304 Grade).
4. Humidity Generation: Chamber has a stainless steel water reservoir at the bottom which is heated through immersion type heaters to generate steam, creating humid conditions inside the chamber.
5. Humidity Level: Humidity ranges from 90% to 95% ± 3% (not adjustable).
6. Water Supply: Bottom reservoir location and interior drain replenishes the water supply, reducing the need for a technician to monitor the water level.
7. Door System: Outer front double walled door is insulated and fitted with a magnetic tape for air-tight closing (no temperature loss), provided with a lock and key arrangement. Features a full view inner plexi-glass door.

OPTIONAL ACCESSORIES

1. Controlling of Temperature: By Profile Digital Microcontroller having 4 Programmers each of 16 steps (total 64 steps of ramp / soak profile).
2. PLC Based Control Systems: With Touch Screen Display with Direct Thermal / Dot Matrix Printer.
3. LCD Controller with Data Logger: (16×2) with optional RS-485 communication ports, cables, and windows-based software with inbuilt data recording.
4. Communication Port: Interface and data cable to download data directly to your PC.
5. Timer: With reverse 0-24 hours for regulating hours of light and darkness, including fitting at the top of the incubator.
6. Regulated Voltage: By Automatic Voltage Stabilizer.
