CONDUCTIVITY METER GGT – 1701

CONDUCTIVITY METER (MODEL NO. GGT-1701)

ZEXTER – A Pioneer in Lab Solutions

Digital Conductivity Meter is designed for conductivity measurement with a 4-digit LED display and ATC (Auto Temperature Compensation). The instrument provides convenient digital measurement with a user-friendly operating menu.

The unit is designed to measure Conductivity, TDS, Temperature and Salinity. It is equipped with soft-touch keyboard switches for convenient operation and provides adjustable cell constant and temperature coefficient settings.

The Cell Constant is adjustable from 0.05 to 10.5, while the Temperature Co-Efficient is adjustable from 0.1% to 4.0%. The instrument operates on 230 V ±10% AC power supply.

APPLICATION

• Conductivity Measurement
• TDS Measurement
• Temperature Measurement
• Salinity Measurement
• Laboratory Testing
• Water Testing Laboratories
• Research Laboratories
• Pharmaceutical Laboratories
• Industrial Laboratories

FEATURES

• Digital Conductivity Meter.
• 4-digit LED display.
• ATC (Auto Temperature Compensation).
• Soft-touch keyboard switches.
• User-friendly operating menu.
• Adjustable Cell Constant from 0.05 to 10.5.
• Adjustable Temperature Co-Efficient from 0.1% to 4.0%.
• Conductivity measurement range up to 1000 mS.
• TDS measurement range up to 1000 ppt.
• Temperature measurement range from 0°C to 100°C.
• Salinity measurement range up to 1000 ppt.
• Operates on 230 V ±10% AC power supply.

MEASUREMENT RANGE

• Conductivity: 0-1000 mS
• TDS: 0-1000 ppt
• Temperature: 0-100°C
• Salinity: 0-1000 ppt

RESOLUTION

• Conductivity: 0.01 / 0.1 Micro Siemens
• TDS: 0.01 / 0.1 ppm
• Temperature: 0.1°C

TECHNICAL SPECIFICATIONS

• Model: GGT-1701
• Type: Digital Conductivity Meter
• Display: 4-Digit LED Display
• Temperature Compensation: ATC (Auto Temperature Compensation)
• Keyboard: Soft Touch Switches
• Cell Constant: Adjustable, 0.05-10.5
• Temperature Co-Efficient: Adjustable, 0.1%-4.0%
• Conductivity Range: 0-1000 mS
• TDS Range: 0-1000 ppt
• Temperature Range: 0-100°C
• Salinity Range: 0-1000 ppt
• Conductivity Resolution: 0.01 / 0.1 Micro Siemens
• TDS Resolution: 0.01 / 0.1 ppm
• Temperature Resolution: 0.1°C
• Power Supply: 230 V ±10% AC

CONDUCTIVITY RANGES

• Range 1: 0-200 µS
• Range 2: 0-2 mS
• Range 3: 0-20 mS
• Range 4: 0-200 mS
• Range 5: 0-1000 mS
