HIGH TEMP.MUFFLE FURNACE -1500°C
“ZEXTER”
Model No. GGT-704
G. G. Technologies
ZEXTER LAB SOLUTION
Manufacturer of Hospital, Institute, Industries, Agriculture, Pharmaceutical lab Testing Equipment’s
High Temperature Muffle Furnace is elegantly designed in various applications for Educational R&D labs, Chemical, Pharma, and Steel Industries & Foundries & Treatment of samples under high temperature.
Low Cost option for heating the material on high temperature.
SALIENT FEATURES & CONSTRUCTION OF HIGH TEMPERATURE MUFFLE FURNACE
- Floor Model Type.
- Heating by Imported Silcarb make silicon Carbide Rods.
- Thermal loss is prevented by ceramic fiber insulation in space between the outer body & heating chamber.
- Easily Replaceable Carbide Rods.
- Saves Energy up to 30%.
- Outstanding Temperature Reliability.
- Having large surface radiation ratio to enhance thermal efficiency and power consumption.
- Duly controlled by accurate thryister device
- Chamber made of Ceramic Zirconium Board.
- Fitted with heavy hinges & door is duly insulated.
- Elements are placed horizontally in the chamber.
- Fitted with R TYPE thermocouple & silver fuse for protection of chamber.
- Control panel fitted with MPC make fuzi (japan) up to 1350°c with sensor. Temperature is controlled by electronic digital temperature indicator cum controller from 100°C to 1350°C, ±5°C fitted on the front panel for easy operations.
- Temperature is displayed by Digital LED with SV and PV display at front of the Furnace (Optional).
- Operating Voltage: 220 Volts / 440 volt (optional) AC (50 Hz).
TECHNICAL SPECIFICATIONS & ORDERING INFORMATION OF HIGH TEMPERATURE MUFFLE FURNACE
| Model No. | HTMF-1 | HTMF-2 | HTMF-3 | HTMF-4 |
| Inner Chamber in MM (W x H x D) | 100 x 100 x 225 | 125 x 125 x 250 | 150 x 150 x 300 | 200 x 200 x 300 |
| Inches Conversion | 4 x 4 x 9 | 5 x 5 x 10 | 6 x 6 x 12 | 8 x 8 x 12 |
| Rating in KW | 2.5 | 4.0 | 5.0 | 7.0 |
| Temperature Range | Maximum Temperature is 1600°C and working temp. 1450°C Heating By Silicon Carbide Rods | |||
| Temp. Controller | Duly controlled by Accurate thryister device | |||
| Temp. Controller | By Microprocessor Based PID Digital Temperature Indicator cum Controller (Optional) | |||
| Temp. Sensitivity | ±5°C by digital electronic controller | |||
| Voltage Operating Voltage | 220 Volts AC (50 Hz) | |||
OPTIONAL FEATURES OF HIGH TEMPERATURE MUFFLE FURNACE
Controlling of Temperature
By Profile (Micro Programmable Controller) (FUZI JAPAN MAKE)
