Gyratory Sieve Shaker Model No. GGT – 1207

Gyratory Sieve Shaker

Model no-GGT-1207

G. G. Technologies
ZEXTER
LAB SOLUTION
Manufacturer of Hospital, Institute, Industries, Agriculture

Introduction:

We offers table Gyratory Sieve Shaker assists in producing uniform motion for shaking. It is used for research and development, quality control of raw materials, as well as in production monitoring. The automated test sieve shaker plays an important role in many Quality Control programs. Quality managers from a wide range of manufacturing settings, including those found in the pharmaceutical, cosmetic, chemical and food processing industries, rely on mechanized test sieve shakers to ensure that the products they produce are of consistent quality and composition, regardless of when or where they are produced. This is because these shakers are the key to conducting effective particle-size analysis using sieve testing methods.

Tapping sieving

A horizontal circular motion overlies a vertical motion which is created by a tapping impulse. These motional processes are characteristic of hand sieving and produce a higher degree of sieving for denser particles (e.g. abrasives) than throw-action sieve shakers

Benefits of Using an Automated Test Sieve Shaker for Particle-Size Analysis:

1. More Consistent and Accurate Results. The first mechanical test sieve shaker was designed to replicate the hand motions used in manual testing scenarios. By automating this process, test sieve shakers are able to provide a much higher level of continuity throughout the testing process. As a result, they can produce more accurate and repeatable results regardless of when or where a test is performed.
2. Increased Efficiency. Manually shaking test sieves is both time consuming and labor intensive. A mechanical sieve shaker is able to replicate and replace the human input needed to perform this type of testing. This means that more material can be tested in less time and with fewer resources invested.
3. Cost Savings. Employing humans to conduct these tests represents ongoing costs in the form of wages and fringe benefits. In addition, downtime related to illness or personal absences also translates into lost productivity and increased opportunity cost. The modern shaker is both reliable and durable. As a result, it doesn’t require a lot of expensive maintenance or need replaced often. Over time, these factors can translate into substantial cost savings.

Based on these reasons, it is easy to see how the automated test sieve shaker has vastly improved the use of sieve testing to perform particle-size analysis for Quality Control purposes.

Specification:

Heavy-duty floor model. The shaker is suitable for heavy materials; powders or granules. The sieve table is inclined to the vertical axis and the direction of inclination changes progressively, in a clock wise direction. In addition to the gyratory motion 15 R P M. of the table, there is an upward and downward movement of tapping is 188 per min, ensuring that each square centimeter of the sieve is utilised; The whole gear mechanism runs in Grease because it fill with Grease.

Operation on: 1/2 (12″) or 1/4 H.P(8″). Motor, 220/230V Single phase, 50 Hz. Main AC
For 18″ adapter use 1/2 H.P. Motor 220/230V, 50 Hz Main AC

Accommodate:-

• a) Sieve diameter 8″ / 12″
• b) Sieve Height 50mm.
• c) Maximum sieves 6 Nos. plus
• d) Others: Upper Lid and Bottom Receiver
