ZEXTER HUMIDITY CABINET – MODEL NO. GGT-412 (Heating)

ZEXTER HUMIDITY CABINET – MODEL NO. GGT-412

G.G. TECHNOLOGIES
Manufacturers of Hospital, Institute, Industries, Agriculture, Pharmaceutical, Lab Testing Equipments[cite: 15]

SALIENT FEATURES

1. Reliable[cite: 15].
2. Precise Control Of Environmental Parameters[cite: 15].
3. Micro-processor based Controllers[cite: 15].
4. Aesthetically designed[cite: 15].
5. Corrosion Resistant interior and exteriors[cite: 15].
6. Energy Efficient[cite: 15].
7. Sturdy Construction[cite: 15].
8. Low Maintenance[cite: 15].
9. Light Weight[cite: 15].

CONSTRUCTION DETAILS

1. Cabinet Structure: Pre-fabricated double walled cabinet with 50 mm thick insulation between the interior, convection heated[cite: 15].
2. Outer Body: Constructed out of thick PCRC sheet duly pre-treated with primers and rust proofing, and elegantly powder coated[cite: 15].
3. Inner Body: Made of heavy gauge stainless steel sheet of SS-304 grade[cite: 15]. The gap between the walls is filled with high grade mineral glass wool to ensure maximum thermal efficiency[cite: 15].
4. Door System: Provided with two doors. The inner door is made of toughened glass with a magnetic door closer to view specimens without disturbing the internal temperature[cite: 15]. The outer door is made of mild steel sheet lined with stainless steel from inside and features a lock and key arrangement[cite: 15].
5. Air Circulation: The unit is mounted on a sturdy steel frame[cite: 15]. The triple walled back of the cabinet is provided with air circulation fans on both sides for uniform temperature maintenance throughout the cabinet[cite: 15].
6. Shelves: Provided with 03-04 customized shelves in various configurations to suit individual requirements[cite: 15].

HEATING & HUMIDITY SYSTEMS

1. Heating: Indirect heating system comprising air heaters made of high grade Kanthal A-1 wires[cite: 15]. Warm air is evenly distributed via efficient motor fans[cite: 15].
2. Humidity Generation: Humidity is generated by means of an aerosol humidity generator equipped with an efficient humidity controller cum indicator[cite: 15].
3. Humidity Range & Control: Range varies from 45% to 90% ±3% to 5%[cite: 15]. It is monitored by a microprocessor-based controller cum indicator, and includes 1 extra humidity sensor with an extra indicator for internal cross-checks[cite: 15].
4. Temperature Range & Control: Microprocessor-based temperature controller cum indicator manages the temperature[cite: 15]. Temperature range spans from ambient 5°C to 100°C, ±1°C[cite: 15].
5. Control Panel: Front panel comprises main on/off switches, heating and mains indicator lamps, microprocessor-based digital temperature and humidity controllers, a 24-hour digital timer, and voltmeters[cite: 15].

TECHNICAL PARAMETERS
