LAMINAR AIR FLOW (VERTICAL) GGT – 503

LAMINAR AIR FLOW (VERTICAL) GGT 503

G.G. TECHNOLOGIES
ZEXTER
A PIONEER NAME IN LAB SOLUTIONS
MANUFACTURERS OF HOSPITAL, INSTITUTE, INDUSTRIES AGRICULTURE, PHARMACEUTICAL, LAB TESTING EQUIPMENTS

CONSTRUCTION DETAILS OF VERTICAL LAMINAR AIR FLOW

BASIC CONSTRUCTION:

Our Vertical laminar air flow benches are designed to conform to the United States federal standard 209B/BS5295 and meets the class 100 conditions. Our units are fabricated of.S. 304 garde. The inner portion of all our laminar air flows are S.S 304 grade. The Outer Portion made up of M.S duly powder coated. The working table also is made of heavy gauge stainless steel sheet of grade ss-304. Front Door made of transparent tempered glass/Acrylic with weight balance movement. The side panels made out of heavy plexi glass sheets are mounted on anodized aluminum frames. The whole unit is supplied with differential manometer to gauge/ Magnehelic Guage the pressure drop in the unit while operation, beside the gas cock, power socket etc.

FILTER ASSEMBLY

All our laminar air flows are fitted with fully washable synthetic pre-filter units and secondary high efficiency perfect air (HEPA) filters made of mini pleated non woven fabric. The efficiency of our filters have a rating better than 99.99% at DOP (cold) and 99.97% at DOP (Hot). Our units have the capacity to hold all suspended particles of size 0.3 micron. Velocity at the output of HEPA is 0.35 to 0.50 m/sec.

MOTOR AND BLOWER ASSEMBLY:

All our Vertical laminar air flow units are provided with perfectly balanced (Static as well as dynamic) motor and blower motors bearing ISI mark. The rating of the assembly is 1/5 HP. Our high efficiency pumps which have life long lubricated bearings ensure a trouble free operation for a long time.

ILLUMINATION:

All the units are provided with adequate illumination at the work table by means of fluorescent lights panel concealed at the upper portion of the unit. This light arrangement conforms to the guidelines laid down in US federal standard. The illumination at the work table is approx 800 lux

ULTRA VIOLET LIGHT

Optimal wattage ultra violet light is incorporated in the illumination panel of our laminar air flow to take care of the sterilization of the existing air present in the enclosure, thus ensuring the high standard of cleanliness in our equipment before the commencement of actual working.

NOISE LEVEL:

Our laminar air flow bench are designed to ensure that the work enclosure have minimum possible vibration levels and noise level is also contained below 55 db.

SALIENT FEATURES:

• Ergonomic Design
• Versatile Usage
• Low Noise And Vibration Levels
• Conforms to US Federal Standard 209 В
• Calibration And Protocol Documentation

TECHNICAL MATRIX: VERTICAL LAMINAR AIR FLOW

APPLICATIONS:

Our Vertical laminar air flows have a variety of applications such as

• Quality control labs of pharmaceutical Industries
• Quality control labs of food processing industries
• Quality control labs of micro circuit and electronic assembly and manufacturing applications.
• Deoxy Ribonucleic Acid Thermo cycling
• General Laboratory applications in Biotechnology
• General Laboratory applications Microbiology
• General Laboratory applications Tissue Culture
• General Laboratory applications Genetic engineering
