WATER BATH SHAKER
(Model no. -GGT-207)
G.G.Technologies.
ZEXTER
LAB SOLUTION
Manufacturer of Hospital, Institute, Industries, Agriculture, Pharmaceutical lab Testing Equipment’s
APPLICATIONS:
ZEXTER Double Walled Water Bath Incubator Shaker is a versatile equipment to study on tissue metabolism, Enzymes and Protein Coagulation or other experiments requiring shaking of subject matter at constant speed under controlled temperature environment.
Double Walled Water Bath Incubator Shaker is low-cost options for Biotechnology, Clinical, Environmental, Micro Biology, Medical, or Industrial Applications.
SALIENT FEATURES & CONSTRUCTION:
- Inner bath chamber made up of Stainless Steel (SS-304 grade) food grade corrosion free.
- Outer chamber and lid made of Stainless Steel (SS-304 grade)
- Heating by immersion heaters.
- Temperature range Ambient (37°C) +5 to 80°C.
- Controls temperature within an accuracy of ±1°C by microprocessor based digital temperature indicator cum controller.
- Thermal loss is prevented by filling Glass/mineral wool (Insulation) in space between the outer body & stainless-steel tank.
- Shaking mechanism comprises of variable speed motor fixed on the left side and coupled to the oscillating tray riding on ball rollers oscillated through a geared variable speed motor. Tray shakes in linearly to and from is with Minimum Noise and Vibration.
- Shaking motion of tray is controlled by speed regulator fitted at the panel.
- Fitted with PMDC heavy duty motor for continuous operation.
- Shaking tray can either hold test tubes or Erlenmeyer flasks/Reagent bottles of 25 ml or 50ml or 100 ml or 250 ml or 1000ml, as ordered by the user
- Supplied complete with one shaking tray as a standard accessory.
- Supplied with GABLED DOME LID for dripping of all condensate into the bath inside periphery.
- Fitted with THYRISTOR BASED DC DRIVE for speed range from 5 to 50 cycles per minute to work on 220/230V AC supply.
TECHNICAL SPECIFICATIONS:
| Model No | WBS-12 | WBS-30 | WBS-18 |
|---|---|---|---|
| Internal Dimensions (LXWXD) | 400 x 300 x 150mm | 455 x 455 x 150mm | 275 x 275 x 150mm |
| Capacity (Approx.) | 18 Ltr | 30 Ltr | 12 Ltr |
| Tray Size | 455 x 455 mm | 400 x 300 mm | 275 x 275 mm |
| Heating Load (Approx.) | 1000 W | ||
| Top Lid | GABLED DOME LID made of Stainless Steel | ||
| Temperature | Controlled by microprocessor based digital temperature indicator cum controller. | ||
| Temperature Range | Ambient (37°C) +5 to 80°C. | ||
| Control Panel | Mains, Heating, Load ON/OFF, individual LED Indicator | ||
| Temperature Accuracy/ Stability | ±1°C | ||
| Display Resolution | 0.1°C | ||
| Temperature Display | Digital LED with set value (SV) & process value (PV). | ||
| Temperature Sensor | RTD (Pt-100) (A – Class) | ||
| Drain system | Fine Quality drain valve for release water | ||
| Shaking Speed | 5 to 50 cycles/min | ||
| Shaking Stroke length | 25 mm | ||
| Shaking Speed Control | Controlled by speed regulator | ||
| Shaking Tray | Can either hold test tubes or Erlenmeyer flasks / Reagent bottles of 25ml or 50 ml or 250 ml or 500 ml or 1000 ml as ordered by the users | ||
OPTIONAL FEATURES:
| Temperature control by | By profile (Micro Programmable) controller |
| Spare Shaking Tray | With Lotus Clamp or Test Tube Rack |
| Speed Indication | By Digital RPM Indicator |
| Communication Port | with interface and data cable to download data to your PC |
