Refrigerated Circulating Water Bath
(CHILLER)
Model No. GGT – 211
G.G. TECHNOLOGIES
ZEXTER
A PIONEER NAME IN LAB SOLUTIONS
MANUFACTURERS OF HOSPITAL, INSTITUTE, INDUSTRIES AGRICULTURE, PHARMACEUTICAL, LAB TESTING EQUIPMENTS
APPLICATIONS
Most ideal for external temperature control applications to external systems such as Rotary Vacuum Evaporators, Refractometers, Polarimeters, Fermenters, Electrophoresis Chamber, Chromatography Columns, Condensers, Rheometers, and general laboratory cooling applications.
ADVANTAGES & BENEFITS
- A compact refrigerated/heating circulator.
- Eliminates the hassles of using a separate heating Bath & a separate Chiller.
- Builts in circulator pump for efficient circulating processes.
- It offers highest level of performance, flexibility and control for the most demanding applications.
- Low noise level.
- Wide operating ranges and applications.
CONSTRUCTIONAL FEATURES
- Inner bath chamber & lid made of Stainless Steel (SS-304 Grade).
- Outer body made of CRC sheet duly powder coated.
- Space between inner and outer chamber filled with high grade PUF insulation for minimal thermal losses.
- High Condensation efficiency.
- Adjustable working temperature ranges available.
- Environment friendly CFC FREE refrigerants and hermetically sealed compressor used.
- Reduces tap water consumption thus reducing high cost of water and waste water.
- Waste water does not contain hazardous substances thus eliminating danger to personnel and environment caused by solvents.
STANDARD FEATURES
- Various temperature ranges available to choose from depending upon varied requirements and applications.
- Microprocessor based autotune PID TEMPERATURE CONTROLLER
- Tighter cooling control for reduced energy consumptions.
- Internal circulation enables precise temperature stability/uniformity in the bath better than ±0.5°C.
- Temperature Display Resolution 0.1°C
- Powerful stirring circulation pump with 15 Lpm capacity at zero head for water.
- Do not use water below 5°C (use ethanol below 5°C).
- To work on 220/230 volts, 50/60 Hz AC supply.
TECHNICAL SPECIFICATIONS & ORDERING INFORMATIONS
| MODEL | TEMPERATURE RANGE | CAPACITY | HEATER LOAD |
|---|---|---|---|
| RCWB-a | 0°C to +100°C | 4/6/8/13 ltrs | 500 Watts |
| RCWB-b | 0°C to +100°C | 23/33 ltrs | 1.0/1.5 KW |
| RCWB-c | -10°C to +100°C | 13/23 ltrs | 1.0 KW |
| RCWB-d | Ambient to 0°C (Cooling Only) | 4/6/8/13 ltrs | – |
| RCWB-e | Ambient to -20°C (Cooling Only) | 13/23 ltrs | – |
| RCWB-f | Ambient to -30°C (Cooling Only) | 4/6/8/13 ltrs | – |
