PAPER INCINERATOR GGT – 706

PAPER INCINERATOR (MODEL NO. GGT-706)

ZEXTER – A Pioneer Name in Lab Solutions

Incinerator is designed as an effective Bio-Medical Waste Treatment equipment for small Nursing Homes, Blood Banks, Veterinary Hospitals and Poultry Farms. The unit is designed for quick and safe disposal of waste.

The Incinerator works on the principle of thermal destruction using controlled combustion. It consists of a dual-chamber system designed to provide sufficient heat for converting waste into a disposable state.

The combustion chamber is well insulated and provided with a high-temperature safe dosing and exhaust system. It provides treatment of flue gases for safe disposal through a long stack.

The primary or burning chamber operates at a temperature of up to 850°C, while the secondary chamber operates at up to 1000°C.

APPLICATION

• Nursing Homes
• Blood Banks
• Veterinary Hospitals
• Poultry Farms
• Waste Treatment Applications
• Quick & Safe Waste Disposal

FEATURES

• Designed for quick and safe disposal of waste.
• Dual-chamber construction for controlled thermal destruction.
• Primary burning chamber temperature up to 850°C.
• Secondary chamber temperature up to 1000°C.
• Well-insulated combustion chamber to minimize heat loss.
• High-temperature safe dosing and exhaust system.
• Flue gases are treated before disposal through a long stack.
• Front-loading design for convenient operation.
• Portable construction suitable for installation in small spaces.
• Whole unit mounted on sturdy wheels for easy movement.
• Door fitted with hinges and handle for proper sealing.
• Strong insulation using insulating bricks and silicon fiber insulating blanket.
• Available in multiple capacities as per requirements.
• Microprocessor controlled digital temperature controllers.
• Safety M.C.B. provided in the control panel.

WORKING PRINCIPLE

The Incinerator works on a furnace-type principle associated with burning refuse. The unit operates through thermal destruction using a controlled combustion chamber.

The combustion process provides sufficient heat to destroy the waste and convert it into a disposable state. The dual-chamber configuration provides a primary burning chamber and a secondary chamber for high-temperature operation.

CONSTRUCTION

The combustion chamber is well insulated and incorporates a high-temperature safe dosing and exhaust system. Strong thermal insulation is provided using a combination of insulating bricks and silicon fiber insulating blanket to minimize heat loss.

The unit is designed as a front-loading system and is portable in nature, allowing it to be conveniently installed in a small space or corner of a building.

The door is fitted with hinges and a handle for proper sealing to minimize heat loss. The complete unit is mounted on sturdy wheels for easy movement.

TECHNICAL SPECIFICATIONS

• Model: GGT-706
• Type: Paper Incinerator
• Chamber Type: Dual Chamber
• Primary/Burning Chamber Temperature: Up to 850°C
• Secondary Chamber Temperature: Up to 1000°C
• Primary Chamber Heating Element: A-1 Kanthal Wire, 14 Gauge
• Secondary Chamber Heating Element: A-1 Kanthal Wire, 17 Gauge
• Insulation: Insulating Bricks & Silicon Fiber Insulating Blanket
• Loading Type: Front Loading
• Construction: Portable
• Mobility: Mounted on Sturdy Wheels

AVAILABLE CAPACITIES

• 5 Kg
• 10 Kg
• 15 Kg
• 20 Kg
• 25 Kg
• 35 Kg
• 50 Kg
• Customized Capacity as per Requirement

CONTROL PANEL

• Temperature Controllers: 2 Nos. Microprocessor Controlled Electronic Digital Temperature Controller cum Indicators.
• Main Line Indicator: Red neon indicator glows when power supply is available to the unit.
• Load Indicator: Green neon indicator glows when power supply to the heaters is ON.
• Rotary Switches: Provided for starting and operating the machine.
• Safety: M.C.B. provided for electrical safety.
