BULK DENSITY APPARATUS (DIGITAL) GGT – 1580

BULK DENSITY APPARATUS (DIGITAL) (MODEL NO. GGT-1580)

ZEXTER – A Pioneer in Lab Solutions

Digital Bulk Density Apparatus is specially designed to meet the requirements of IP/USP standards. The unit is constructed with M.S. duly powder coated for durability and reliable laboratory operation.

The Bulk Density Apparatus is designed to hold two cylinders of 100 ml and 50 ml capacity. Its mechanism provides simultaneous rotating and tapping motion to the cylinders, allowing the sample under test to be packed evenly and uniformly.

The apparatus is equipped with a digital counter controller having a range of 1 to 999 counts and a 3-digit LED count display. It is powered by a 24-volt motor and provides variable speed from approximately 20 to 70 RPM.

APPLICATION

• Bulk Density Testing
• Powder Density Testing
• Sample Packing & Tapping
• Pharmaceutical Laboratories
• Quality Control Laboratories
• IP/USP Standard Testing

FEATURES

• Specially designed to meet IP/USP standard requirements.
• M.S. body with powder coated finish.
• Designed to hold two cylinders simultaneously.
• Supports 50 ml and 100 ml cylinders.
• Simultaneous rotating and tapping motion.
• Provides even and uniform packing of the sample under test.
• Digital counter controller with 1 to 999 count range.
• 3-digit LED count display.
• 24-volt motor.
• Variable speed from approximately 20 to 70 RPM.
• Operates on 230 Volts AC, Single Phase power supply.
• 50 ml, 100 ml and 250 ml round-base cylinders are available.

CONSTRUCTION

The Digital Bulk Density Apparatus is constructed with an M.S. body duly powder coated. The apparatus incorporates a mechanism that provides simultaneous rotating and tapping motion to the cylinders for uniform packing of the sample under test.

The unit can accommodate two cylinders and is designed for reliable laboratory testing according to IP/USP requirements.

TECHNICAL SPECIFICATIONS

• Model: GGT-1580
• Type: Digital Bulk Density Apparatus
• Digital Counter Controller: 1-999 Counts
• Count Display: 3-Digit LED
• Motor: 24 Volts
• Variable Speed: 20-70 RPM Approx.
• Power Supply: 230 Volts AC, Single Phase
• Number of Cylinders: 2 Nos.
• Standard Cylinder Capacity: 50 ml & 100 ml
• Available Cylinders: 50 ml, 100 ml & 250 ml Round Base
• Body Material: M.S. Powder Coated
• Standards: IP/USP

CYLINDER OPTIONS

• 50 ml: Round Base Cylinder
• 100 ml: Round Base Cylinder
• 250 ml: Round Base Cylinder
