WATER BATH “ZEXTER”
MODEL NO-GGT-203
G.G.Technologies
ZEXTER
LAB SOLUTION
Manufacturer of Hospital, Institute, Industries, Agriculture, Pharmaceutical lab Testing Equipment’s
SALIENT FEATURES:
- Versatile usage.
- Ergonomic Design
- Energy Efficient
- Long life
- Low Maintenance
CONSTRUCTION:
Our water baths are double walled convection heated units. Outer body of our water baths are constructed out of thick PCRC steel sheet, duly pre-treated with primers for rust proofing and duly powder coating/S.S. 304 grade. The inside chamber of the unit is made of heavy gauge stainless steel sheet of grade ss-304. The Bath lid made of stainless steel with 6 holes/ 12 holes steel concentric rings.
Built in Noiseless long lasting Magnetic Field circulating pump for efficient circulating processes. Offers highest level of performance, flexibility and control for most demanding applications. Built in circulator pump (Magnetic Field / FHP Pump) for efficient circulating processes. Offers highest level of performance, flexibility and control for most demanding applications.
HEATING:
Indirect heating system is provided in our water bath, comprising of air heaters made of high grade Kanthal A-1 wires of suitable wattage. The temperature is evenly distributed throughout the chamber through natural water convection mechanism, ensuring very good temperature sensitivity.
TEMPERATURE RANGE:
Temperature range of our standard water bath models are 5°C ambient to 95°C. However, we have the capacity to modify the same to suit the individual specialized requirements of our customers.
Thermostatically controlled double walled rectangular stainless steel water bath with three concentric lids, to use beakers/ flasks from 50 ml to 500 ml capacity, with digital thermometer range 0 to 110 degree centigrade of 0.1-degree centigrade resolution at 50 degrees centigrade
TEMPERATURE SENSITIVITY:
Temperature inside our water bath is controlled with a sensitivity of ±0.5°C or better. (With PID Controller)
FRONT PANEL:
Front panel of our water bath comprises of on/off switches heating and mains Indicator lamps and temperature controller.
| Model No. | Dimension | Holes Configuration |
|---|---|---|
| WBDW-1 | 300 x 250 x 150mm | 6 holes of 3″ Dia |
| WBDW-2 | 300 x 300 x 150mm | 9 holes of 3″ dia |
| WBDW-3 | 350 x 400 x 150mm | 12 holes of 3″ Dia |
TECHNICAL SPECIFICATION:
| Temperature Control | ±°C | 0.5 or better |
| Temperature Sensitivity | ±°C | 0.5 or better |
| Spatial Deviation In Temperature | °C | 0.1 |
| Readability Temperature range | °C | 5°C above ambient to 95°C |
| Temperature Sensor | PT-100 | |
| Temperature Controller | Solid State digital Controller/PID optional | |
| Display | Coloured LED | |
| Timer | 1 to 999 mins | |
| Power consumption | ||
|---|---|---|
| Nominal power | W | 1000-1500W |
| Nominal voltage | 220-230 Volts, 50 Hz Single Phase | |
| Frequency | 50 | |
