Seed Germinator Single Chamber GGT-1102

ZEXTER SEED GERMINATOR (SINGLE CHAMBER) – MODEL NO. GGT-1102

G.G. TECHNOLOGIES
Manufacturers of Hospital, Institute, Industries, Agriculture, Pharmaceutical, Lab Testing Equipments

APPLICATIONS

1. “ZEXTER” brings the ultra-high-tech Triple walled Microprocessor controlled, solid-state Seed Germinator used for normal germination applications and for various other tests involving micro-organisms, plants, tissues, electronic components etc.
2. Used for plant growth, biological studies, forestry research works propagation of seeds, and incubation that requires a controlled environment (hot/cold cycles and light dark operations).

CONSTRUCTION

1. Outer chamber is made of Mild Steel duly pre treated & finished with powder coated paint for lasting finish.
2. Inner chamber made of STAINLESS STEEL SHEET (304 Grade).
3. Chamber has stainless steel water reservoir at bottom is heated through immersion type heaters generates the steam thus creating humid condition inside the chamber.
4. Humidity from 90 to 95% plus minus 3% (not adjustable). Bottom reservoir location and interior drain replenishes water supply, reducing the need for technician to monitor water level.
5. Outer front double walled door is insulated and is fitted with magnetic tape for air tight closing for no temperature loss, provided with lock and key arrangement.
6. A full view inner plexi-glass door enables inspection and monitoring of inner chamber specimens without disturbing the process temperature.
7. Door operated illumination lamp is fitted inside the chamber for easy visibility.
8. Fitted with durable coaxial blower for forced air circulation at triple walled back to maintain temperature uniformity in the chamber.
9. User oriented design of shelves makes you adjust each space of shelves without difficulty.
10. Heating elements are placed in the path of moving air duly insulated from the body.
11. Cooling is done by finned tube evaporator lie in the air circulation path by ISI marked Compressor/Condensing Units CFC free & R-134 a eco friendly refrigerant.
12. High grade Glass Wool / Puf Insulation between outer and inner chamber for minimal thermal losses.
13. Fitted with Control Panel with advanced micro-processor based technology housed at the top fitted with Temperature controller cum Indicator Microprocessor based with LED display for Set Value (SV) & Process Value (PV) to select any desired temperature provided with Volt meter on the panel to read the incoming voltage.
14. Safety Thermostat to prevent over heating.
15. Caster wheel mounted for easy portability.
16. Supplied with cord and plug. Operating Voltage: 220 Volts AC (50 Hz).

SIZES & CAPACITIES

TECHNICAL SPECIFICATIONS

OPTIONAL ACCESSORIES
