ZEXTER CO2 INCUBATOR (CARBON DI OXIDE INCUBATOR) – MODEL NO. GGT-419
G. G. Technologies / TEXTER LAB SOLUTION
Manufacturer of Hospital, Institute, Industries, Agriculture, Pharmaceutical lab Testing Equipment’s
SALIENT FEATURES
- Reliable.
- Aesthetically designed.
- Energy Efficient.
- Long life.
- Low Maintenance.
CONSTRUCTION & FEATURES
- Cabinet Structure: Double walled convection heated units designed for optimal thermal efficiency.
- Outer Body: Constructed out of thick PCRC sheet, duly pre-treated with primers and rust-proofing, and elegantly powder-coated.
- Inner Chamber: Made of heavy gauge stainless steel sheet of SS-304 grade.
- Insulation: The gap between the walls is filled with high-grade mineral glass wool to ensure maximum thermal efficiency.
- Door System: Provided with two doors. The inner door is made of thick plexi-glass/float glass with a magnetic door closer to view specimens without disturbing the chamber temperature. The outer front double-walled door is made of mild steel sheet lined with stainless steel from inside and features a lock and key arrangement.
- Air Circulation: The triple-walled back of the incubator is provided with two air circulation fans for uniform maintenance of the temperature throughout the chamber.
- Shelves & Lighting: Supplied with two stainless steel shelves. Door-operated illumination lamps are fitted inside the chamber for easy visibility.
- Capacity & Power: Has a capacity of 100 liters and is designed to work on 220/230 Volts A.C. supply.
HEATING & CO2 CONTROL SYSTEMS
- Heating System: Features an indirect heating system. Temperature is controlled from ambient +5°C to 60°C (Standard range up to 70°C) with an accuracy of ±0.5°C.
- Temperature Controller: Fitted with a Microprocessor-based digital temperature indicator-cum-controller.
- Cooling System: Equipped with a CFC-free eco-friendly compressor.
- CO2 Control: Fitted with a microprocessor controller for CO2 with a range of 0-20% to maintain CO2 gas levels precisely.
TECHNICAL PARAMETERS
| Parameter | Specification Details |
|---|---|
| Temperature Sensitivity | ±0.5°C or better |
| Spatial Deviation In Temperature | ±0.5°C or better |
| Readability | 0.1°C |
| Temperature Range | 5°C to 70°C (Standard) |
| Temperature Sensor | PT-100 |
| Chamber Size | 18(W) x 15(D) x 24(H) inches |
| CO2 Sensor | NDIR Japan |
| CO2 Range | 0-20% |
| Temperature Controller | Micro Processor Based Digital Temperature Controller |
| Display | LED |
| Adjustable Alarm Limits | Optional (With PID controller only) |
| Safety Thermostats | Yes |
| Nominal Voltage | 220-230 Volts, Single Phase, 50 Hz |
