ZEXTER BACTERIOLOGICAL INCUBATOR / LAB INCUBATOR – MODEL NO. GGT-401
G. G. Technologies / TEXTER LAB SOLUTION
Manufacturer of Hospital, Institute, Industries, Agriculture, Pharmaceutical lab Testing Equipment’s
SALIENT FEATURES OF INCUBATOR
- Versatile usage.
- Ergonomic Design.
- Energy Efficient.
- Long life.
- Low Maintenance.
CONSTRUCTION DETAILS
- Cabinet Structure: Incubators are double walled convection heated units designed for maximum thermal efficiency.
- Outer Body: Constructed out of thick PCRC sheet, duly pre-treated with primers and elegantly powder coated.
- Inner Chamber: Made of heavy gauge stainless steel sheet of SS-304 grade.
- Insulation: The gap between the walls is filled with high grade mineral glass wool to ensure maximum thermal efficiency.
- Shelves: Supplied with one to three stainless steel shelves (inner size ke mutabik).
HEATING & TEMPERATURE CONTROL SYSTEM
- Heating System: Indirect heating system comprised of air heaters made of high grade Chrome wires of suitable wattage.
- Air Distribution: Warm air is evenly distributed throughout the chamber through efficient motor fans ensuring very good temperature sensitivity.
- Temperature Range: Standard temperature range is 5°C above ambient temperature to 60°C (customers ki requirement ke mutabik modify bhi kiya ja sakta hai).
- Temperature Sensitivity: Controlled with a sensitivity of ±0.5°C.
- Temperature Controller: Controlled by a Micro Processor Based PID temperature Indicator cum controller with a Digital Timer (999 mins / 9999 mins).
MODEL SIZES & CAPACITY
| Model No. | Inner Chamber Size (w x h x d) | Approx Liters |
|---|---|---|
| BIN-1 | 300 x 300 x 300 mm | 28 |
| BIN-2 | 350 x 350 x 350 mm | 43 |
| BIN-3 | 450 x 450 x 450 mm | 90 |
| BIN-4 | 450 x 450 x 600 mm | 105 |
| BIN-5 | 450 x 600 x 600 mm | 120 |
| BIN-6 | 600 x 600 x 600 mm | 215 |
| BIN-7 | 600 x 900 x 450 mm | 240 |
| BIN-8 | 600 x 900 x 600 mm | 325 |
TECHNICAL SPECIFICATION
| Parameter | Specification Details |
|---|---|
| Temperature Sensitivity | ±0.5°C or better |
| Spatial Deviation In Temperature | ±0.5°C or better |
| Readability | 0.1°C |
| Temperature Range | Ambient +5°C to 60°C |
| Temperature Sensor | PT-100 |
| Temperature Controller | Microprocessor Based PID Controller |
| Display | LED/LCD |
| Safety Thermostats | Yes |
| Timer | Digital Timer 999 mins / 9999 mins |
| Shelves | 1 to 3 Nos. Stainless Steel |
| Nominal Voltage | 220-230 Volts, Single Phase, 50 Hz |
MANUFACTURER DETAILS & CONTACT
G. G. Technologies
An ISO 9001 & CE Certified Company
Registered Address: J-11/86, Sanjay Market, Wazirpur, Delhi-110052
Office Landline: +91-11-45509084
Mobile No.: +91-9873067889, 8595224635
Websites: www.ggtechnologies.co.in, www.zexterindia.com
