Rotary Vacuum Evaporator GGT – 1401-M

ROTARY VACUUM EVAPORATOR

MODEL NO-GGT-1401/M

0052

The Rotary Evaporator series from ZEXTER Brand, offers an incomparable performance to price advantage. With reliability ensured due to its company ide operating practices as per ISO 9001:2008, CE, WHO GMP standards and its ability to design & deliver feature rich User-friendly product.

ADVANTAGES:

• Spark-less drive unit Heavy duty DC motor with variable speed regulation
• Digital RPM LED display of motor.
• Manual Quick Action lifting system for unit.
• Unit can adjust/stop at any stage in up & down position and also can tilt at any angle/degree.
• Micro Processor Based Digital Temperature Controller for Water/oil Bath.
• PTFE/silicon glass sealing mechanism.

CONSTRUCTION:

The Equipment has been designed for ease of use and dependability.Starting from the raw material stage to mid-process inspections, every Evaporator final test is done in a state of the art Test Room by Qualified Engineers as per standards for its performance across all its specifications. Every single Evaporator is delivered along with a signed Test Report.

• Smooth, adjustable, maintenance free and user friendly one touch motorized lift.
• Oil Bath with efficient insulation.
• Stainless Steel Round Bath inner vessel.

STANDARD FEATURES:

• Drive Speed with assured speed control from 20 to 150 RPM. WITH DC DRIVE CONTROL MECHANISM
• Oil Bath with energy efficient heater range ambient +5 to 100 °C.
• Power Supply: 230 VAC, 50 Hz, single phase.

OIL FREE-DIAPHRAGM PUMP

Zeer

• Portable and handy.
• Continuous rated motor.
• In / out nozzles Air displacement 45 lit/min. double stage
• Use of vapours / vacuum trap is highly recommended

OPTIONAL ACCESSORIES

• Vacuum Pump- Diaphragm type (Double Stage)
• Vacuum Regulator – Analogue type
• Glass Moisture Vacuum Trap with silica gel
• Round Oil Bath – Digital up to 200°C
• 2 mtr silicon pipe

VACUUM REGULATOR – ANALOGUE:

Use of a Vacuum Regulator with a suitable vacuum pump enhances solvent recoveries to above 90%.

• Ideal partner for EVAPORATOR.
• Easy readout with large analogue dial; Range 0 to 760 mm/Hg.
• Compatible with any laboratory vacuum source.
• Glass monitor trap for prevent material in vacuum pump chemical vapour.

ROUND OIL BATH – DIGITAL:

• Suitable for Oil with temperature range up to 200°C.
• SS inner body with energy efficient contoured bottom.
• SS tubular immersion heater.
• Can be used for other applications in the laboratory also.

TUBING’S SET:

• Tap adapter 1 no for connecting to normal tap.
• NBR pipe for vacuum connection. (2 Mtr.)
