AIR CURTAIN GGT-513

AIR CURTAIN (MODEL NO. GGT-513)

ZEXTER – A Pioneer in Clean Room Solutions

We are manufacturers of Air Curtain in India since last two decades. We strongly believe in the principle of quality first and everything else to follow, which is reflected in our products. We specialize in both standard and customized models of Air Curtain specially designed to meet various special requirements of our customers across India and abroad.

Our Air Curtain is a modern device which, when installed on a door, forms an invisible curtain of continuous air and thus prevents escape of conditioned air as well as entry of outside hot, humid and polluted air. It thus not only cuts down your electricity bill, but also helps in maintaining cleanliness and hygiene up to the required standard.

In other words, Air curtains are aerodynamically designed air blowers generating a laminar stream of air with sufficient quantity (cfm) and speeds (velocity) to offer the desired environment protection through open doorways / service hatches. Sharp Air Curtains are available in various models (both horizontal & vertical) and in five different velocities. They are suited for door openings starting from 2.5 Ft. Wide and in velocities ranging from 13 mtr/sec to 27 mtr/sec. These velocities are divided into five different models for the convenience of our privileged customers. It is most suitable for height up to 12 feet; it is available in two models: one for up to 08 feet height called Standard velocity model, and another one is for 12 feet height called High Velocity model.

APPLICATION

• Pharmaceuticals & Food Industries
• Laboratories
• Clean Rooms
• Computer Facilities
• Cold Storages
• Show Rooms & Restaurants
• Electrical & Electronic Industries

FEATURES

• Our Air curtains are quiet enough not to disturb occupants, allowing efficient continuous operation in all installations.
• The seasons in which doors can be left open are extended with air screens. Customers are attracted to shops with open doors.
• Heated units give a feeling of welcoming warmth as the customer enters the space, plus the entrance remains dry.
• The reduction in drafts through the openings increases the energy efficiency of the building.
• The air velocity is optimized to reduce entry of insects, pollen and dust, while not disturbing occupants.
• Our air curtains are elegantly styled and installation is simple.
• Superior motor technology ensures reliable operation and long-life span.
• Standard velocity model available.

TECHNICAL SPECIFICATIONS

Air Curtains made out of 20 Gauge Powder Coated M.S. Sheet, Fitted with 1/5 H.P. Single Phase motor and 120mm × 135mm dynamically Balanced Plastic Blowers.

MODELS AND SPECIFICATIONS TABLE

• Size 30: Motor: 01 | Blower (Aluminium): 02 | Velocity: 17-19 Mt./Sec. (At Nozzle)
• Size 36: Motor: 01 | Blower (Aluminium): 02 | Velocity: 17-19 Mt./Sec. (At Nozzle)
• Size 42: Motor: 01 | Blower (Aluminium): 02 | Velocity: 17-19 Mt./Sec. (At Nozzle)
• Size 48: Motor: 01 | Blower (Aluminium): 02 | Velocity: 17-19 Mt./Sec. (At Nozzle)
• Size 60: Motor: 02 | Blower (Aluminium): 04 | Velocity: 17-19 Mt./Sec. (At Nozzle)
• Size 72: Motor: 02 | Blower (Aluminium): 04 | Velocity: 17-19 Mt./Sec. (At Nozzle)
• Size 84: Motor: 02 | Blower (Aluminium): 04 | Velocity: 17-19 Mt./Sec. (At Nozzle)
• Size 96: Motor: 02 | Blower (Aluminium): 04 | Velocity: 17-19 Mt./Sec. (At Nozzle)
