ULTRASONIC CLEANER (DIGITAL) (MODEL NO. GGT-1562)
ZEXTER – A Pioneer in Lab Solutions
The Ultrasonic energy is produced by converting electrical energy into mechanical vibrations by using a generator and piezo electric transducers. Due to mechanical vibrations in the cleaning liquid, this phenomenon is called cavitation. In a very short time, it removes all dirt & foreign bodies from components which are immersed in the cleaning liquid.
APPLICATION
- Dental Clinic
- Electroplating
- Ophthalmology
- Pharmaceutical
- Surgical
- Jewellery
- Electronics
- Machine Tools
- Automobile
- Watch Industry
SALIENT FEATURES
- Continuous Self Tuning Circuitry for any change in workload, liquid level and bath temperature.
- Uniform cavitations throughout the tank.
- Separate oscillator eliminates damage to generator in case of failure of transducers.
- Using 40 kHz frequency for effective cleaning with low noise.
- Designed for complete cleaning of small and large components without dismantling.
- Inner tank and outer body made of Stainless Steel.
EFFECTIVELY REMOVES
- Dust
- Dirt
- Rust
- Grease
- Wax
- Flux
- Finger Prints, etc.
TECHNICAL SPECIFICATIONS
- Models: GGT-3, GGT-6, GGT-9, GGT-12, GGT-25
- Capacity: 2.5L to 24L
- Ultrasonic Power: 100W to 500W
- Heating Power: 100W to 500W
- Degas Function: Yes
- Memory: Yes
- Time Setting: 1-99
- Heating Temperature: RT+5°C to 80°C
- Display: Digital BLUE LED
- Frequency: 40 kHz
- Lid Material: SS 304
- Inner Tank Material: SS 304
- Outer Tank Material: SS 304
- Power Supply: AC 220V, 50/60 Hz
- HSN Code: 84562000
MODELS AND SPECIFICATIONS TABLE
| Specification | GGT-3 | GGT-6 | GGT-9 | GGT-12 | GGT-25 |
|---|---|---|---|---|---|
| Capacity | 2.5L | 5L | 8L | 11L | 24L |
| Tank Size (mm) | 240×140×100 | 300×155×150 | 300×240×150 | 330×300×150 | 500×300×200 |
| Overall Size (mm) | 270×170×240 | 330×180×310 | 330×270×310 | 360×330×310 | 550×330×360 |
| Ultrasonic Power | 100W | 150W | 200W | 300W | 500W |
| Heating Power | 100W | 300W | 300W | 400W | 500W |
| Dimension (L × W × H) | 393×257×334 mm | 485×275×415 mm | 494×373×415 mm | 534×445×427 mm | 710×443×480 mm |
| Weight (Approx.) | 4.8 kg | 8.7 kg | 9.6 kg | 14.5 kg | 20.9 kg |
COMMON SPECIFICATIONS
| Degas Function | Yes |
| Memory | Yes |
| Time Setting | 1-99 |
| Heating Temperature | RT+5°C to 80°C |
| Display | Digital BLUE LED |
| Frequency | 40 kHz |
| Lid Material | SS 304 |
| Inner Tank Material | SS 304 |
| Outer Tank Material | SS 304 |
| Power Supply | AC 220V, 50/60 Hz |
| HSN Code | 84562000 |
