TISSUE FLOTATION BATH GGT – 206

TISSUE FLOTATION BATH (MODEL NO. GGT-206)

ZEXTER – A Pioneer Name in Lab Solutions

The double walled Tissue Flotation Bath is used for precise control of different samples at constant temperature. It is most ideal for Histological, Chemical, Clinical and Bacteriological Laboratories and is used to stretch and dry cut tissues.

It is ideal for tissue culture, enzyme reactions, fermentation, tissue section processing, etc. for preparing distortion-less and wrinkle-free tissue specimens. Its exact temperature regulation ensures evenly stretched cuttings that are clearly visible in the anodized bath.

The cuttings are carefully dried on the warmed rim of the bath. The unit offers a high level of performance, flexibility and control for demanding laboratory applications.

APPLICATIONS

• Histological Laboratories
• Chemical Laboratories
• Clinical Laboratories
• Bacteriological Laboratories
• Tissue Culture
• Enzyme Reactions
• Fermentation
• Tissue Section Processing
• Stretching and Drying of Cut Tissues
• Preparation of Distortion-Less and Wrinkle-Free Tissue Specimens

SALIENT FEATURES & CONSTRUCTION

• Double walled construction.
• Inner tank is made from a single piece of black anodized aluminium.
• Housing is made of powder coated aluminium.
• Front panel consists of temperature regulator knob, mains switch and pilot lamp.
• Inside surface is black and the outer surface is finished in powder paint.
• Wide rim provided for drying wet slides.
• Exact temperature constancy of ±2°C.
• Thermal loss is prevented by mineral wool insulation between the outer body and inner tank.
• Heating elements are positioned in the floor and side walls for better temperature distribution.
• Natural mixing of the medium provides uniform temperature distribution throughout the bath.
• Temperature is controlled by an imported capillary type thermostat.
• Low bath depth allows comfortable and safe working.
• Supplied with Dust Guard Lid made of black anodized aluminium.

TECHNICAL SPECIFICATIONS
